12x1020mm Self-Locking Nylon Cable Ties / 12.4x1020mm PA66 Zip Ties

Products

Product Name: Self-locking Nylon Cable Ties
Product Code: 12×1020
Product Dimensions: 12.4x1020mm
Product Material: PA66
Available Colors: Black, White, Red, Yellow, Blue, Green (Other colors available upon request)
Other Specifications:

规格型号 Item No.	宽度 Width		长度 Length		最大捆绑直径 Max.Bundle Dia.		最小拉力 Min.Tensile Strength
规格型号 Item No.	mm	inch	mm	inch	mm	inch	kg	lbs
XG-3×60	2.5	0.098	60	2.4	11	0.43	8	18
XG-3×80			80	3	16	0.63
XG-3×100			100	4	22	0.87
XG-3×120			120	5	30	1.18
XG-3×150			150	6	35	1.38
XG-3×200			200	8	50	1.97
XG-3×260			260	10	65	2.56
XG-3×300			300	12	80	3.15
XG-3×380			380	15	105	4.14
XG-4×100	3.6	0.142	100	4	22	0.87	18	40
XG-4×150			150	6	35	1.38
XG-4×180			180	7	42	1.65
XG-4×200			200	8	50	1.97
XG-4×250			250	10	65	2.56
XG-4×300			300	12	80	3.15
XG-4×350			350	14	100	3.94
XG-4×370			370	15	105	4.14
XG-4×400			400	16	110	4.33
XG-4×500			500	20	150	5.91
XG-5×100	4.8	0.189	100	4	22	0.87	22	50
XG-5×120			120	5	30	1.18
XG-5×150			150	6	40	1.58
XG-5×200			200	8	50	1.97
XG-5×250			250	10	65	2.56
XG-5×300			300	12	80	3.15
XG-5×350			350	14	90	3.55
XG-5×380			380	15	102	4.02
XG-5×400			400	16	105	4.14
XG-5×450			450	18	130	5.12
XG-5×500			500	20	150	5.91
XG-5×550			550	22	160	6.30
XG-5×600			600	24	170	6.70
XG-5×740			740	29	220	8.67
XG-5×920			920	36	265	10.44
XG-8×150	7.6	0.299	150	6	33	1.30	55	121
XG-8×200			200	8	50	1.97
XG-8×250			250	10	65	2.56
XG-8×300			300	12	80	3.15
XG-8×350			350	14	90	3.55
XG-8×380			380	15	100	3.94
XG-8×400			400	16	105	4.14
XG-8×450			450	18	110	4.33
XG-8×500			500	20	150	5.91
XG-8×550			550	22	165	6.50
XG-8×600			600	24	170	6.70
XG-8×650			650	26	190	7.49
XG-8×700			700	28	200	7.88
XG-8×750			750	30	220	8.67
XG-10×200	9	0.354	200	8	50	1.97	80	176
XG-10×300			300	12	80	3.15
XG-10×400			400	16	105	4.14
XG-10×450			450	18	120	4.73
XG-10×500			500	20	150	5.91
XG-10×550			550	22	160	6.30
XG-10×600			600	24	170	6.70
XG-10×650			650	26	185	7.29
XG-10×700			700	28	200	7.88
XG-10×760			760	30	225	8.87
XG-10×800			800	32	243	9.57
XG-10×900			900	35	265	10.44
XG-10×1000			1000	39	295	11.62
XG-10×1200			1200	47	340	13.40
XG-10×1500			1500	59	470	18.52
XG-12×230	12.4	0.488	230	9	57	2.25	114	251
XG-12×290			290	11.4	76	2.99
XG-12×380			380	15	100	3.94
XG-12×480			480	19	135	5.32
XG-12×530			530	21	155	6.11
XG-12×580			580	23	170	9.70
XG-12×650			650	26	190	7.49
XG-12×750			750	30	225	8.87
XG-12×800			800	32	243	9.57
XG-12×850			850	33.5	238	9.38
XG-12×920			920	36	277	10.91
XG-12×1020			1020	40	308	12.14
